Sub Layers:
Name: Overland Flow Paths 2021
Display Field:
Type: Group Layer
Geometry Type: null
Description: <DIV STYLE="text-align:Left;font-size:12pt"><DIV><P><SPAN>Overland flow paths were derived from a flow accumulation surface that was extracted from a hydrologically corrected DEM. Flow paths were defined using a flow accumulation threshold of 500 cells, i.e. to qualify for inclusion in the flow path network, a minimum catchment area of 2,000 m2 was required (500 cells x 4 m2 each). OLFPs were delineated iteratively, with additional burn lines created with each iteration to correct flow paths that spill out of their channels and follow an incorrect trajectory. This is often caused by manmade structures such as bridges but also natural features such as dense vegetation incorrectly included within the DEM (as opposed to the surface model or DSM). Additionally, significant stormwater pipes were utilised as these pipes are unlikely to reach capacity and have a significant role in the conveyance of water. Several iterations using this approach were conducted until a fair representation of the flow paths was obtained. Flow paths were first converted to vector polylines. The resulting feature class can be visualized by symbolizing on the catchment area.</SPAN></P></DIV></DIV>
Service Item Id: 7a9fc3d738ea4b5a9611e1b7ca8170e8
Copyright Text: Morphum Environmental
Default Visibility: true
MaxRecordCount: 0
Supported Query Formats: JSON, geoJSON, PBF
Min Scale: 20000
Max Scale: 0
Supports Advanced Queries: false
Supports Statistics: false
Has Labels: false
Can Modify Layer: false
Can Scale Symbols: false
Use Standardized Queries: true
Supports Datum Transformation: true
Extent:
XMin: 1649923
YMin: 5989874
XMax: 1760924
YMax: 6096227
Spatial Reference: 2193
(2193)
